Analog Way SMART QUAD - Ref. SQD200 Programmer's Guide User Manual
Page 24
24
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SET_CROP_WIN_POS_H
SI
SI
Cropping window horizontal
position
Rd/Wr 0
65535 32768
Percent = 65535 = 100% : all
cropping on the left
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_CROP_WIN_POS_V
SJ SJ
Cropping window vertical position Rd/Wr 0
65535 32768
Percent = 65535 = 100% : all
cropping on the top
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_CROP_WIN_SIZE_H
SK SK Horizontal cropping
Rd/Wr 0
58981 0
Percent = 65535 = 100%
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_CROP_WIN_SIZE_V
SL SL
Vertical cropping
Rd/Wr 0
58981 0
Percent = 65535 = 100%
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
