Analog Way SMART QUAD - Ref. SQD200 Programmer's Guide User Manual
Page 23
23
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SET_USER_GAIN_G
sg
sg
ADC G channel adjustment
(advanced setting)
Rd/Wr 0
255
128
128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_USER_GAIN_B
sb
sb
ADC B channel adjustment
(advanced setting)
Rd/Wr 0
255
128
128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_PULLDOWN_2_2
Sn Sn
Enable/disable the auto 2:2
pulldown
Rd/Wr 0
1
1
0 = Disable automatic detection
1 = Enable automatic detection
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_PULLDOWN_3_2
Sp Sp
Enable/disable the auto 3:2
pulldown
Rd/Wr 0
1
1
0 = Disable automatic detection
1 = Enable automatic detection
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
