54

Group

Name

CmdResp Description

Read /
Write

Min
Value

Max
value

Default
value

Values

Index #1

Index #2

OUTPUT

OFORMAT

OF OF Output format

Rd/Wr 0

37

0

0 = PAL
1 = NTSC
2 = 480p
3 = 576p
4 = SMPTE296M
5 = SMPTE260M
6 = SMPTE274M
7 = SMPTE274M
8 = SMPTE274M
9 = 640 x 480 4/3
10 = 848 x 480 16/9
11 = 800 x 600 4/3
12 = 1024 x 768 4/3
13 = 1360 x 768 16/9
14 = 1280 x 800 16/9
15 = 1280 x 1024 5/4
16 = 1400 x 1050 5/3
17 = 1680 x 1050 16/9
18 = 1600 x 1200 4/3
19 = 1920 x 1200 16/9
20 = 2048 x 1080
21 = 1280 x 720 16/9
22 = 1920 x 1080 16/9
23 = 1920 x 1080 16/9 (HD)
24 = 1920 x 1080 16/9 (SHARP)
25 = 1920 x 1080 16/9 (SHARP 2)
26 = 1440 x 900 16/10
27 = 1280 x 768 15/9
28 = 1366 x 800 15/9
29 = 1366 x 768 16/9
30 = Computer Custom 1
31 = Computer Custom 2
32 = Computer Custom 3
33 = Computer Custom 4
34 = Computer Custom 5
35 = Computer Custom 6
36 = Computer Custom 7
37 = Computer Custom 8

0 = Main output
1 = Preview
output
2 = Recording
output
