Analog Way SMART QUAD - Ref. SQD200 Programmer's Guide User Manual
Page 16
16
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SIG_DETECTED_FORMAT
sD sD
Input detected format name
Rd
0
42
0
0 = None
1 = Invalid
2 = Unknown
3 = SDTV NTSC
4 = SDTV PAL
5 = SDTV SECAM
6 = SDTV BW
7 = SDTV 480i
8 = SDTV 576i
9 = EDTV 480p
10 = EDTV 576p
11 = HDTV 720p
12 = HDTV 1035i
13 = HDTV 1080i
14 = HDTV 1080p
15 = HDTV 1080sF
16 = CPU VGA
17 = CPU 800x480
18 = CPU WVGA
19 = CPU SVGA
20 = CPU 1280x600
21 = CPU 720p RGB
22 = CPU XGA
23 = CPU WXGA
24 = CPU SWXGA
25 = CPU 800p RGB
26 = CPU SWXGA+
27 = CPU 1152x864
28 = CPU 900p RGB
29 = CPU 1600x900
30 = CPU 960p RGB
31 = CPU SXGA
32 = CPU 1360x1024
33 = CPU DILA4/3
34 = CPU SXGA+
35 = CPU WSXGA+
36 = CPU 1080p RGB
37 = CPU 2K
38 = CPU UXGA
39 = CPU WUXGA
40 = CPU 1920x1440
41 = CPU QXGA
42 = CPU 1366x768
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
6 = Input7
8 = Input9
9 = Input10
10 = Input11
11 = Input12
