AltiGen MAX1000/MAX2000 Telephony Boards
Telephony Hardware Manual 49
In addition, there are differences in the system resources provided by the embedded
DSP board. In the MAX1000-R, the DSP board supports:
• Up to 96 extensions
• 6 extension-based conference bridges—6 parties per conference, with a maximum
of 24 parties at any one time
• Up to 12 G.723/G.729/G.711 IP channels and 48 G.711-only IP channels
• Extension recording but not trunk recording
Additional Hardware
The MAX1000-R hardware differs from MAX1000 hardware in the following ways:
• Supports two ALTI-M0404-T1E1 spans, instead of one
Note: When you are using two T1 or E1 spans, and one is used as a back-to-back
tie trunk and the other is a live CO line, the live T1 or E1 line must connect
to the top slot.
Note: When no T1/E1 or one T1/E1 board is installed, you can select:
• 30 G.723/G.729/G.711 IP channels, OR
• 12 G.723/G.729/G.711 IP channels plus 48 G.711-only IP channels
When two T1/E1 boards are installed, the configuration will switch to 12
G.723/G.729/G.711 IP channels and 48 G.711-only IP channels
automatically.
• SATA RAID controller
• Supports SATA RAID1 with 80GB hard disk
• 1GB RAM
System Limitation for MAX1000-R
• Trunk recording is not supported. Only extension recording is supported.
MAX2000 System
The MAX2000 system uses the same DSP board and supports all the same analog and
digital access boards as the MAX1000 and MAX1000-R.
The MAX2000 hardware differs from the MAX1000 hardware in the following ways:
• Hot swappable power supply (2x250W)
• Hot swappable RAID1 with 2x80GB hard disk
• Pentium Processor
• 1GB RAM
• Supports two ALTI-M0404-T1E1 spans, instead of one
The MAX2000 system is manufactured with two different DSP configurations, MAX2000
standalone server and MAX2000iG:
• MAX2000 Server—In standalone server mode, the MAX2000 Server supports the
same software features and uses the same firmware as the MAX1000-R.
When no T1/E1 or one T1/E1 board is installed, you can select:
