Parameter 15. Alternate Count-By (5) 34
Parameter 16. Alternate Units Conversion Factor (45,360) 34
Parameter 17. Full Scale Graduations (10,000) 34
Parameter 18. Overload Graduations (10,200) 34
Parameter 19. Deadload Offset (automatically set) 34
Parameter 20. Disable Power-on Zero (1[power-on zero disabled]) 35
Parameter 21. Deadload Factor (automatically set) 35
Parameter 22. Weight Conversion Factor (automatically set) 35
I/O Port Parameters 35
Parameter 23. Serial Port 1 Mode (4[8 data bits, no parity]) 35
Parameter 24. Serial Port 1 Baud Rate (1[9600 baud]) 36
Parameter 25. Serial Port 2 Mode (4[8 data bits, no parity]) 36
Parameter 26. Serial Port 2 Baud Rate (1[9600 baud]) 36
Parameter 27. TX2 Control / Station ID (255[single station]) 37
Parameter 28. TX2 Format (2[Condec data format]) 37
Printer Parameters 38
Parameter 30. Auto Line Feed after Carriage return (1[yes]) 38
Parameter 31. End of Print Character (12[form feed]) 38
Parameters 32, 33, 34, 84, 85, 86, 87, 88 and 90 Print Labels 38
Parameters 35, 36, 37 and 38. Print Codes 39
Parameter 39. TTL Remote Control (1[ttl in = scale basic function]) 39
Display Intensity, Watch Dog Timer 40
Parameter 40. Display intensity (10) 40
Parameter 41. Battery Enable (0[optional clock needed]) 40
Parameter 42. Enable Watch Dog Timer (0) 40
Fixed Registers 40
Parameter 43-50. Fixed Registers 40
Keyboard Events 40
Parameters 51-58. Keyboard Event Functions 40
PARAMETER FUNCTIONS 41
Function 59. Display Calibration Audit Number 43
Function 60. Calibrate Scale (deadload first) 43
Function 61. Calibrate Scale (span first) 43
Function 62. Calibrate (deadload only) 44
Function 63. Adjust Gain Calibration 44
Function 64. Configure Passwords 45
Function 65. Configure Print Formats 46
Function 66. Configure Time and Date 51
Function 67. Display Operation Parameters 51
Function 68. Print Operation Parameters 51
Function 69. Diagnostic Tests 52
Function 70. Initialize Operation Parameters to Factory Default 52
Function 71. Configure Event monitor 53
Function 72. Scale Basic Function Editor 53
Function 73. Select Mode of Operations 54
Function 74. Configure Timers 55
Function 75. Enable Peak Detect 55
Function 76. Debug Mode 55
Function 78. Initialize ID Memory 55
Function 79. Enable Multi-point Linearization 55
Function 80. Multi-point Linearization Calibration 56
