Industrial Data Systems IDS 430 User Manual
Page 36

IDS 430/433 Users Manual Version 1.0
- 36 -
Parameter 24 Serial Port 1 Baud Rate (1 [9600 baud])
Enter a baud number from the table below to select a baud rate from the
description column. (*HS baud rates for the 100 samples per sec version only).
Baud Number
Baud Description
1
9600 Baud
2
4800 Baud
3
2400 Baud
4
1200 Baud
5
600 Baud
6
300 Baud (* HS 19.2K)
7
150 Baud (*HS 38.4K)
Parameter 25 Serial Port 2 Mode (4 [8 data bits, no parity])
Enter the mode number from the table below to select the mode parameter in the
mode description column.
Mode Number
Mode Description
1
7 data bits, no parity
2
7 data bits, even parity
3
7 data bits, odd parity
4
8 data bits, no parity
5
8 data bits, even parity
6
8
data bits, odd parity
Parameter 26 Serial Port 2 Baud Rate (1 [9600 baud])
Enter a baud number from the table below to select a baud rate from the
description column. (*HS baud rates for the 100 samples per sec version only).
Baud Number
Baud Description
1
9600 Baud
2
4800 Baud
3
2400 Baud
4
1200 Baud
5
600 Baud
6
300 Baud (* HS 19.2K)
7
150 Baud (*HS 38.4K)
