QUICK START
9
Controlling Dimmers
From the main menu select screen choose 1 to load Main Menu 1. From Main
Menu 1, select 2 - Transmit DMX512. The DMX 512 transmit function is now
displayed:
Transmit DMX512 Transmit DMX512
Data Entry Data Entry
CH??? CH??? @??% @??%
From this screen, standard level setting commands can be used to transmit DMX
dimmer levels. Enter 1 THRU 40 @ 30 OK. DMX channels 1 through 40 are
now being transmitted at 30%. Subsequent commands will pile on levels to
previous entries on a last take precedence basis while in data entry mode.
Enter 41 AND 75 @ 15 OK. DMX channels 41 and 75 are now being transmitted
at 15%, while channels 1 through 40 are held at 30%.
To blackout or turn all dimmers off, enter 1 THRU 512 @ OFF OK.
