DMXDart Operation
19
When actually controlling individual moving lights, they are called up as fixture
numbers. Fixture number 1 will be patched by the DMXDart to the fixture who’s
DMX address was set in the DMX offset. Fixture 2 will be patched to the address
calculated by using the Group Offset and the DMX Offset, and so on. This
patching process continues for the total number fixtures you have under your
control.
To enter the setup menu from the Moving Light TX display press MENU then 4-
Setup to enter the moving light setup submenu. Press 1 - Parameters to enter
the ML Parameters submenu.
Moving Light Model
To select the type of moving light being controlled, press 1 –ML# Select. You
should see something like this:
ML# Select ML# Select
Technobeam (full) Technobeam (full)
Select ML:078 Att=18 Select ML:078 Att=18
^ ^
The DMXDart fixture library assigns a unique number to each model of moving
light. To choose the model of moving light you wish to control, you have to select
its corresponding fixture number. To make this easy, The DMXDart displays
both the fixture number and the fixture model name on the moving light selection
display.
The cursor will appear under the moving light number. From this location a
moving light can be selected via direct digital entry or by using the Ý and Þ
keys. As the moving light numbers are scrolled through, the model and the num-
ber of attributes that fixture utilizes are displayed.
Once the desired moving light has been selected, Press MENU to return to the
ML Parameters submenu.
