DMXDart Operation
29
The packet counter (top right of the display) begins to count the DMX data
packets received. To cycle the display between the minimum, nominal (average)
and maximum values, press the Ü key to move the cursor below the value being
received. Then press the Ý or Þ to change to the desired parameter.
The parameters that can be analyzed are:
BRK – Break Length
MAB – Mark after break
MBF – Mark Between Frames
MBP – Mark between packets
BTB – Break to Break
FPP – frames per packet
PPS – packets per second.
If the parameter being analyzed is outside of the recommended specification for
USITT DMX512-1990, an error message will be displayed beside the abnormal
value.
TIP:
For more information on DMX characteristics, please refer to United States
Institute for Theatre Technology DMX512/1990 Digital Data Transmission
Standard for Dimmers and Controllers. This publication is available for purchase
at http://www.usitt.org
Receive DMX Setup
Within Rx Setup, 3 parameters can be adjusted to tailor the way DMX receive
functions display and operate.
•
Start Code Select – View data for a single, user defined, start code
•
Termination – Turn on DMX termination when the DMXDart is the last
DMX receiving device in a daisy chain.
•
Thru-trans control – Set the output port (DMX thru) off, as a direct pass
through, or transmit a regeneration of the incoming signal. When
regenerating the signal, the DMX “flavor” can be chosen, effectively acting
as a DMX to DMX converter.
Flicker Finder
The Flicker Finder is a long-term test designed to detect fluctuating levels
(corrupt data) within a static DMX512 signal. The test compares a snapshot, or
individual packet of DMX512 levels against every incoming packet, and displays
inconsistencies. To test a DMX transmission device for “flickers”, go to DMX
transmit mode (Main Menu 1) and set a static look of DMX Levels such as 1-512
@ 50.
