LCD-KIT
P a g e 29
6.1 Us e r Mo d e OS D Stru c tu re
6.1.1 OS D Bu tto n s
There are several on-screen-display (OSD) control buttons oriented vertically along the
left side of the monitor rear panel.
Figure 6-1 shows a typical arrangement of OSD controls of the LCD-KIT series LCD
monitor.
Figure 6-1: OSD Control Buttons
6.1.2 OS D Me n u S tru c tu re
Table 6-1 shows the OSD menu structure for all models of the SRM series LCD monitor.
Level 0 Level 1 Value
Main Display Features Menu Brightness 0 to 100
Contrast 0 to 100
