2.5 Mo u n tin g Op tio n s
Each LCD-KIT series LCD monitor has mounting holes located on the mounting
bracket. Table 2-2 details the number of mounting holes for each model of the LCD-KIT
series LCD monitor. Refer to Section 2.4 for more information.
Mo d e l
No . o f Ro u n d Ho le s - S ize No . o f S lo tte d Ho le s
LCD-KIT170G
6 – 4.5 mm diameter
8
LCD-KIT150G
6 – 4.5 mm diameter
8
Table 2-2: Mounting Holes
