PPC-51xxA-H61 Panel PC
Page 112
6.2.11 K Type Thermocouple Connectors (K_TYPE1/K_TYPE2)
6.2.12 LVDS Backlight Connector (INVERTER1)
6.2.13 LVDS Connector (LVDS1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 LVDSA0+ 4 LVDSA0-
5 LVDSA1+ 6 LVDSA1-
7 LVDSA2+ 8 LVDSA2-
9 LVDSACLK+ 10 LVDSACLK-
11 LVDSA3+ 12 N LVDSA3-
13 GND 14 GND
15 LVDSA4+ 16 LVDSA4-
17 LVDSA5+ 18 LVDSA5-
19 LVDSA6+ 20 LVDSA6-
21 LVDSBCLK+ 22 LVDSBCLK-
PIN NO. DESCRIPTION
1 D-
2 D+
Table 6-12: K Type Thermocouple Connectors (K_TYPE1/K_TYPE2)
Pinouts
PIN NO. DESCRIPTION
1 +12V
2 +12V
3 Backlight ON/OFF
4 Backlight Brightness Control
5 GND
6 GND
Table 6-13: LVDS Backlight Connector (INVERTER1) Pinouts
