UP C-V315-QM77 P a n e l P C
P a g e 13
System
Audio
AMP 3W + 3W (Internal Speaker)
Camera
2M Mega Pixels
Connectivity
Wireless
IEEE 802.11a/b/g/n 3T3R module (WIFI-RT5393-DB-R10)
Bluetooth
Bluetooth V2.0+EDR with USB interface (optional)
3G
Reserved USB connector (Optional)
GPS
FV-W9U (Optional, internal USB header)
Drive Bay
HDD Driver Bay
1 x 2.5” SATA SSD
SSD
mSATA
CD-ROM Driver Bay
N/A
Expansion Slot
1 x PCIe Mini Card
System Cooling
Fanless
Physical
Construction Material
Aluminium alloy
Mounting
VESA 100mm x100mm or 75mm x 75mm with M8 screws
Front Panel Color
Orange (Paintone 15C)
Dimension (WxHxD) (mm)
427.19 x 330.63 x 71.6
Net Weight
7.97KG
Environment
Operation Temperature
-20°C ~60°C
Storage Temperature
-30°C ~70°C
Operating Humidity
5% ~90%, non-condensing
