Parts list – Fill-Rite TS AA Mechanical Precision Meter User Manual

Page 18

1 . 18

Parts List

TS10A,

TS15A

TS20A

TS30A

ITEM

DESCRIPTION

QTY

P/No.

QTY

P/No.

QTY

P/No.

QTY

P/No.

QTY

P/No.

1 Meter

Body

1 MB2560

1 MB2565

1 MB2575

1 MB2395

1 MB5201-1

Depth

across

body:

1.47” (37 mm)

1.97” (50 mm)

3.46” (88 mm)

4.96” (126 mm)

2 Gear

Set,

PPS/carbon,

LV 1 GS560RC 1 GS10RC

1 GS15RC

1 GSTS2HRC 1 GS5201RC

Opt. PPS/carbon,

HT GS560RC-MV

GS10RC-MV GS15RC-MV GSTS2HRC-MV GS5201RC-MV

PPS/carbon,

HV GS560RC-HV

GS10RC-HV GS15RC-HV GSTS2HRC-HV GS5201RC-HV

PPS/Teflon,

LV GS560RT GS10RT

GS15RT

GSTS2HRT

GS5201RT

PPS/Teflon,

HT GS560RT-MV

GS10RT-MV GS15RT-MV GSTS2HRT-MV GS5201RT-MV

PPS/Teflon,

HV GS560RT-HV

GS10RT-MV GS15RT-HV GSTS2HRT-HV GS5201RT-HV

3 Post

Plate

assy. 1 CP25521 1 CP25801 1 CP25802

1 CP2396-2 1 CP23961

***

4 Gear

Plate

assy.,

internal 1 CP25532 1 CP25532 1 CP25532

1 CP23162 1 CP23172

***

Gear

plate

with

bushing

CP25531 CP25531 CP25531 CP23161 CP23171

4b-I Repair

kit,

replacement

combination

gear

set

RKCP1

RKCP2

5 Dowel

pin 4 MS902118-8 4 MS902118-8 4 MS902118-8 4 MS902118-8 4 MS902118-8

6 Screw, for post/gear plates 8 FS9661 8 FS9661

8 FS9661

7 O-ring,

cover,

Viton™ 2 SL1157

2 SL1157

2 SL1167

Opt.

Teflon™

SL2157

SL2167

8 Front

cover

1 CP2550

1 CP2398

9 Rear

cover

1 CP2551

1 CP2397

10 Cover screws 16 FS2900 16 FS2900 16 FS2900 24 FS2928 24 FS2928

11 Packing

gland,

AA/Viton

1 RK2001

1 RK2003

Opt. SS/Teflon RK8002

RK8002

RK80031 RK80031

11b

O-ring,

Viton

SL1212

Opt. Teflon SL2212

SL2212

11cde For 1/10

gallon

GS2001

GS2002

(std) na

21f

Whole

gallon na

GS2001

(opt)

GS2002

1/10

liter

GS2002

(std) GS2002

(std) na

Whole

liter

GS2001

(opt)

GS2001

(opt)

GS2001

GS2002

(std) GS2002

(std)

Whole

dekaliter na

GS2001

(opt)

GS2001

(opt)

12 Retainer,

packing

gland

1 MP9061

13 Screws,

retainer

3 FS9515

14 RAD

(right

angle

drive)

1 RD15911 1 RD15911 1 RD15911 1 RD15911 1 RD15911

15 RAD

dust

cover 1 MP2505

1 MP2505

16 Screws, w seal wire hole 2 FS59121 2 FS59121 2 FS59121 2 FS59121 2 FS59121

17 Screws,

plain 2 FS5912

2 FS5912

18 Set

screw

for

drive

shaft

1 FS9652

19 Calibrator

assy. 1 CA6000

1 CA6000

***

20 Screws,

calibrator

RAD

2 FS2501

21 Drive

shaft

assy,

(A-F) 1 RD15912 1 RD15912 1 RD15912 1 RD15912 1 RD15912

22 Meter

pedestal

1 MP2528

1 MP2526

1 MP2529

23 Split lock washers na na na na na

24 Screws,

for

pedestal

2 FS9923

25 Drain

plug 2 MS4019

2 MS4019

26 Screws, RAD, w seal hole 2 FS59121 2 FS59121 2 FS59121 2 FS59121 2 FS59121
Screws,

RAD,

plain 2 FS5912

2 FS5912

27 Screws,

RAD

cover 4 FS2800

4 FS2800

2 FS2800

28 Lock

washer,

1/4”

4 FS3602

29 Flange or adaptor assy. See pg. 1.14 See pg. 1.14 See pg. 1.14 See pg. 1.14 See pg. 1.14

30 Register

mounting

bolt 4 FS0856

4 FS0856

Time frame for replacement of regular maintenance items and long term consumables (rotors, packing gland & calibrator) varies a great
deal. Factors include user maintenance schedule, fluid lubricity, flow rate versus model capacity, intermittent versus continuous duty & total
volume. In heavy duty service, rotors may last from 2-5 years, while in lighter duty service, they may last from 10-20 years or more.
* = Indicates recommended Spare Parts

(regular maintenance items).

** = Indicates suggested Spare Parts

(longer time frame, but should be on hand if meter is in a location where service is not readily available).

*** = Indicates very long term wearing component

(should be on hand if meter is in a location where service is not readily available).
