Using the Storage Navigator GUI 3-45
Hitachi Universal Storage Platform V/VM Hitachi Storage Navigator User’s Guide
Table 3-6 Status of All Volumes in a Parity Group
Status Description
Normal All the volumes are in a normal status.
Blocked All the volumes are in a blocked status.
Format All the volumes are being formatted.
Preparing Quick Format All the volumes are being prepared for Quick Format.
Normal (Quick Format) Quick Format is in progress. When a parity group contains
both the Normal and Normal (Quick Format) statuses, the
list also displays Normal (Quick Format).
Correction Access The access attributes of all the volumes are being changed.
Copying Data in all the volumes are being copied.
Read Only Hosts can only read the volumes.
Shredding The shredding operation is in progress.
Unknown The system does not recognize the status of any volumes.
Warning Some volumes are not in a normal status.
- The statuses of the volumes are none of the above.
• Page Switching Area:
The Parity Group list displays up to 4,096 parity groups per page. When
more parity groups are defined, use the following functions to see the
entire list:
– List: Displays the current page number. It also allows you to display the
desired page.
– Previous button: Displays the previous page.
– Next button: Displays the next page.
• Status Area:
The Status area displays the status of the disk group that you have
selected in the list.
– Normal: All the volumes are in a normal status.
– Warning: Not all the volumes are in a normal status.
• Detail button:
When you select a parity group in the Parity Group list and click Detail,
all the LDEVs in the parity group are displayed in the LDEV list.
• LDEV List:
The following items are displayed in the LDEV list:
– LDKC:CU:LDEV: From the left the LDKC number, the CU number, and
the LDEV number are displayed. For detailed information, see Common
Elements.
– Status: A status of a volume is displayed.
