Page 50 September 1, 2008 Quadra-Fire · Sapphire · 250-7233H
Item
#
Part Description
Alphabetical Order
SKU
Adapter, DV 7000-162
18 Adapter, Valve Extension 450-6330
Air Shutter Assembly 468-5060
Ash Lip 454-0070
20 Back Shield 455-0200
19 Back Shield Cover Plate 455-0220
22 Baffle 455-0290
21 Baffle Hanger 455-0300
Blower BK-GAS
4 Bulkhead 26457
5 Bulkhead Stop 474-0090
Burner Assembly SN# 007777105 and lower 844-9280
Burner Assembly SN# 007777106 and higher SRV455-5320
7 Burner Pan, Side 455-0530
Burner Stop 7010-152
3 Burner Support 455-0420
Component Pack, Matte Black (Includes ON/OFF Valve; LP Orifice, .063; Mineral Wool; LP Pilot Injector, EZ, LP, 35;
LP Conversion Label; Owner’s Manual; Warranty Card; Touch-up Paint and Fastener.
)
MBK: 455-5130
PMB: 455-5290
PMH: 455-5300
CSB: 455-5340
CWL: 455-5350
17 Control Rod 455-0340
Conversion Kit, LP 844-9730
Conversion Kit, NG 844-9020
Door Assembly 455-5180
Door Assembly, Left See page 52
Door Assembly, Right See page 52
Elbow, .375 ML FLR x .375 200-0720
Elbow, Brass, 3/8 COMP x 3/8 MPT 17524A
Electrode, S.I.T., EZ, Flush 842-4580
Exhaust Cover Plate 455-0730
Face Assembly, Solitaire See page 52
Face, Quartet See page 52
Flex Line, 3/8 Flare x 22L 7000-197
Flue Collar Assembly 455-5120
Gasket, Elbow 460-0610
Gasket, Glass, 10 ft. 844-3010
Glass Assembly 7010-017
Grille Cover 455-0390
Grille, Top Vent See page 52
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When
ordering, supply serial and model numbers to ensure correct service parts.
D.
Service Parts
(cont’d.)
R
SAPPHIRE
(NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 5-19-05
Ending Manufacturing Date:
