Page 30 September 1, 2008 Quadra-Fire · Sapphire · 250-7233H
Figure 8.4 Install the inner flue collar on rear of appliance, with
damper rod pointing up. A dab of high temperature silicone
on the gasket will help gasket adhere to the appliance.
Figure 8.5 Install the inner flue cover on top of the appliance,
ensuring that the damper rod is in the up position.
Figure 8.6 Install the outer flue cover, with damper adjustment
plate attached, to the top of the appliance.
On top of the appliance: Reattach the damper adjustment
with screw.
Figure 8.7 Install the inner collar and outer flue collar on the
rear of the appliance.
Install the rear vent cover plate, supplied iwth the kit, on the
back shield.
Reinstall the cast insert piece in the top of the appliance.
NOTE: A grill cover plate is shipped with the appliance. This
plate may be placed beneath the top grille. The use of the
plate increases blower efficiency and also hides the interior
of appliance from view. See next page for installation instruc-
tions.
Outer Cover Plate
Damper Adjustment Plate
2. Replace Burner Orifice for Horizontal Vent
Configurations
Remove front, glass, and logs (if installed).
Burner Locator
Figure 8.8 To remove the burner pan locators from the left and
right sides of the burner, remove one screw from each side,
lift locators up and out.
