September 1, 2008 Page 23 Quadra-Fire · Sapphire · 250-7233H
6
Gas Information
A. Fuel Conversions
Before making gas connections ensure that the appliance
being installed is compatible with the available gas type.
Any natural or propane gas conversions necessary to meet
the appliance and locality needs must be made by a quali-
fied technician using Hearth & Home Technologies specified
and approved parts.
1. Converting to LP Gas
Figure 6.2 Remove the burner support by loosening the left
screw on the pilot tower, and removing the two screws on
the front side of the burner neck support.
KIT CONTENTS: Replacement orifice; replacement
pilot injector; valve regulator; and conversion label.
TOOLS REQUIRED: Power drill (a 90° handle is help-
ful); #2 Phillips bit; 5/32" Allen wrench; 5/8" open end
wrench.
Figure 6.3 Slide the burner neck support to the left. Pull off
pilot hood and set aside.
NOTE: Gas conversions should only be performed
by a qualified service person, and/or where required
by state and local codes, licensed installer/service
technician. In the Commonwealth of Massachusetts,
installation must be performed by a licensed plumber
or gas fitter.
IMPORTANT NOTE! The orifice supplied with this con-
version kit is for TOP VENT MODELS ONLY. If your stove
was fitted with the rear vent kit, the correct conversion
orifice was supplied WITH THE REAR VENT KIT.
Figure 6.1 Remove front (if installed), glass, and logs (if
installed.) Using the #2 Phillips screwdriver remove the two
(2) 1/4" x 20 screws securing the burner as indicated. Lift
burner out of firebox.
Figure 6.4 Use a 5/32" Allen wrench to remove the pilot
injector.
