Maintenance and Service Guide Index–9
T
telephone jack
location 1–15
pin assignments A–2
thermal grease, replacement
5–26
thermal module, spare part
number 3–14 , 3–28
tools required 4–1
top components 1–20
top cover, spare part number
3–4
TouchPad board
removal 5–57
spare part number 3–4 ,
5–57
TouchPad buttons, location
1–23 , 1–25
TouchPad LED, location
1–23 , 1–25
TouchPad scroll area, location
1–23 , 1–25
TouchPad, location 1–23 ,
1–25
transporting precautions 4–5
troubleshooting
audio 2–26
Computer Setup 2–3
Diagnostics for Windows
2–8
initial 2–12
keyboard 2–29
modem 2–31
network 2–31
nonfunctioning device
2–19 , 2–28
OS loading 2–20
pointing device 2–30
port replicator 2–19
power 2–13
video 2–17
troubleshooting flowcharts
2–11
U
upper logic audio board
removal 5–79
spare part number 3–4 ,
5–79
USB Digital Drive
location 1–17
removal 5–16
spare part number 3–31
USB mouse, spare part number
3–33
USB port
location 1–9 , 1–13 , 1–17
pin assignments A–4
V
vent, location 1–13 , 1–15 ,
1–23 , 1–27
video troubleshooting 2–17
volume buttons, location 1–7 ,
1–11
W
Windows applications key,
location 1–19
Windows logo key, location
1–19
wireless antennae cables, spare
part number 3–4 , 3–16
