Sata cabling, Optional sas controller cabling, Sata cabling optional sas controller cabling – HP PROLIANT DL320 G6 User Manual
Page 50
Cabling 50
IMPORTANT:
Route the cables without blocking the airflow or other installed components.
Use the cable clips installed in the chassis to manage cable routing.
SATA cabling
CAUTION:
When routing cables, always be sure that the cables are not in a position where
they can be pinched or air flow can be blocked.
IMPORTANT:
Route the cables without blocking the airflow or other installed components.
Use the cable clips installed in the chassis to manage cable routing.
Optional SAS controller cabling
