5–6 Maintenance and Service Guide
Removal and Replacement Procedures
5. Remove the hard drive by following these steps:
a. Turn the notebook upside down, with the front
facing you.
b. Remove the two PM2.5×9.5 screws 1 that secure the
hard drive to the notebook.
c. Use the notch 2 on the hard drive cover to lift the rear
edge of the hard drive up and swing it forward 3.
Removing the Hard Drive
d. Remove the hard drive.
Spare Part Number Information
Hard drives (hard drive cover, shield, and connector included with
hard drive and in Miscellaneous Plastics Kits)
80-GB (5400-rpm)
80-GB (4200-rpm)
60-GB (5400-rpm)
60-GB (4200-rpm)
40-GB (4200-rpm)
30-GB (4200-rpm) 350082-001
336992-001
336991-001
336990-001
336989-001
350081-001
