Removal and Replacement Procedures
Maintenance and Service Guide 5–21
5.12 Fan
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.9).
3. Remove the switch cover (Section 5.10).
4. Remove the speaker cover (Section 5.11).
5. Disconnect the fan cable 1 from the system board.
6. Remove the PM2.5×5.0 screw 2 that secures the fan
to the base enclosure.
7. Remove the fan 3.
Removing the Fan
Reverse the above procedure to install the fan.
Spare Part Number Information
Fan 336993-001
The fan is also included with the heat sink, spare part number 337000-001.
