Connecting Video I/O to a Master or HD Station
31
Video I/O without Real-Time Deliverables
The following illustration shows the video I/O wiring for a configuration that does not support
playout to a VTR through the NVIDIA board (Real-time deliverables).
Altinex
VIDEO
INPUT
POWER
9V 600NA
OUT 1
OUT 2
OUT 3
OUT 4
ALTINEX
DA1804NT Video Distribution Amplifier (Computer/ntsc/pal)
Altinex Out 1 to
FX5500 Comp Sync
Altinex Out 2 to
Centaurus Ref In
From HD or SD Analog
Sync Generator
Distribution
amplifier
Graphics Monitor
(HD) SDI Out A to VTR (4:2:2)
(HD) SDI In A from VTR (4:2:2)
Video 1 Out to (HD) SDI VTR Input 1
or 4:2:2 on Display Device*
Video 2 Out to (HD) SDI VTR Input 2
or 0:2:2/4 :0:0 gfx feed on Display Device*
AUDIO
GPI
IN
OUT
IN
DIGITAL AUDIO
OUT
1/2
3/4
7/8
5/6
1/2
3/4
5/6
7/8
WClk
CVBS
RS.422D
LTC
RS 422C
RS.422B
RS 422A
DVS Centaurus Breakout Box
(Front)
(Back)
AES/EBU AUDIO
SYSTEM
AES/EBU AUDIO
VTR Control
RS-422
To LTC on VTR
or other slave device
From Altinex Comp Sync
HP xw8400 Workstation
Real-Time Deliverables*
