Item Specifications
LT01-10A1
LCD Panel Size 9.6-inch TFT
Aspect Ratio 4:3
Best Resolution 800 (horizontal) x 600(vertical)
Maximum Display Area 146.8 mm (H) x 195.4 mm (W)
TV System NTSC
Video System
AV1: CVBS RCA jack
AV2: S-Video or CVBS: 10-pin mini-DIN
Audio System
(Input) AV1: RCA left & right jacks
(Input) AV2: RCA left & right jack on 10-pin mini-DIN
(Output) 3.5mm ø headphone jack
Built-in Speakers 2W + 2W
Power Supply 100~240 V,AC, 50/60 Hz adapter 12V DC
Power Consumption 40W (Average)
Power Consumption (Standby) 5W max. (at 110Vac/60Hz)
Optional Accessories External Speakers
Weight (including base) 2.87kg
Dimensions (including base) 284.74 mm (H) x 340.56 mm (W) x 147.53 mm (D)
