3-90-04301R18_03/13 36 P43 Pellet Stove
Service Parts
P43 Pellet
beginning Manufacturing date: n/a
ending Manufacturing date: active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at depot
iteM description cOMMentS PaRt nuMbeR
1 Hopper Assembly
Pre 008084166
1-10-09537A
1-00-232108
Y
Post 008084166 1-10-09537A Y
Hopper Lid w/Hinge 1-10-08518
Hopper Switch 48" Post 008084166 3-20-232108 Y
Retrofi t Kit for Hopper Extension 1-00-06826 Y
2 Feeder Assembly Refer to following page
3 Flue Tail Pipe 3-00-247237 Y
4 Auger Motor Cover 2-00-773852P Y
5 Auger Motor Shield 2-00-773815P Y
6 Differential Switch 3-20-6866 Y
7 Distribution Blower 3-21-33647 Y
8 Combustion Blower 3-21-08639 Y
Combustion Blower Mounting Screws Pkg of 100 1-00-53483208
9 Rear Cover Left 2-00-773828-1P Y
10 Rear Cover Right 2-00-773828-2P Y
11 Comb Intake Weldment 1-10-08516S Y
12 Retainer Assembly 1-10-08533S Y
13 Ash Pan 1-10-7738108A Y
14 Ash Door Assembly 1-10-7738106A
15 Bolt on Hinge 2-00-06952B
16 Cast Door Frame 4-00-06800P
Cast Door w/Glass 1-10-06800A
17 Glass Panel 3-40-950133125 Y
18
Door Handle Assembly
1-00-453001 Y
contains: handle, 6 mm washer, ShcS, handle, elbow, Paw (cast), SSS, bhcs.
Wooden Handle w/Hardware, Load Door 1-00-00247 Y
19 Burn Pot Weldment 1-10-00675 Y
Flame Guide 3-00-03000 Y
Clean Out Cover 2 Sets 1-00-06623 Y
Thumb Screw Pkg of 10 3-31-782108-10 Y
20
Fire Brick 4-1/2 x 9 x 1-1/4" Pkg of 7 1-00-900450125 Y
Firebrick, Full Skid 414 Pcs 3-40-900450-414
21 Hopper Heat Shield 2-00-773854B
22 Feeder Cover 2-00-773826L
23 Circuit Board w/Knobs & Shafts 1-00-05886 Y
Control Board Label 3-90-06655A
Circuit Board Plate, Studded w/label 1-10-08327
Knob, Contol Board/D-Shaft 25 Sets 1-00-015605 Y
Additional service parts on following page.
