Shading architecture

Smartshader™ technology
Programmable pixel and vertex shaders
16 textures per pass
Pixel shaders up to 160 instructinos with 32-bit floating point precision for
each RGBA component
Multiple render target support
Shadow volume rendering acceleration
High precision 10-bit per channel frame buffer support

Supported graphics APIs

OpenGL 1.5
DirectX 9.0

Available graphics drivers

Available graphics drivers HP-tested: Microsoft Windows XP, Windows 2000, and Linux

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

Maximum Resolution

DVI-I output – drives digital display at resolutions up to 1600x1200

Internal 400MHz RAMDACs – drives dual analog displays up to 2048x1536
@ 85Hz each

NVIDIA Quadro FX 540

NVIDIA Quadro FX 540
PCI-Express Graphics

PCI-Express Graphics

PCI-Express Graphics
Card

Card

Form Factor

ATX, 4.376" x 7.0"
Single slot

Graphics Controller

NVIDIA NV43GL

Bus Type

PCI-Express x16, <75W power consumption

RAMDAC

Dual 400 MHz integrated

Memory

128 MB 275 MHz DDR SDRAM unified frame buffer, Z-buffer and Texture
storage
8.8 GB/sec graphics memory bandwidth

Connectors

DVI-I + VGA + 10-pin HDTV Out (HD cable purchased separately)

Multi-monitor support

Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 75Hz, one digital display at 1600x1200 @
60Hz.

Additional product

Additional product
features

features

128 KB BIOS 3.3V Flash ROM reprogrammable by SW
Hardware accelerated Overlay Planes
Hardware accelerated two-sided lighting
Hardware accelerated antialiased points and lines
3D Volumetric Texture support
Hardware accelerated Occlusion Culling
Compliant with Microsoft/Intel PC2001 Workstation requirements
Video Timings compliant with VESA DMT 1.0 and VESA GTF 1.0
specifications
DDC2B+ Monitor support on all OS platforms
ACPI Version 1.0b Power Management support (all modes)

Shading architecture

Fully programmable GPU (OpenGL1.5/DirectX 9.0c class)
Long fragment programs (up to 65,536 instructions)
Long vertex programs (up to 65,536 instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution
Optimized compilers for Cg, OpenGL shading language, and Microsoft
HLSL

Supported graphics APIs

OpenGL 1.5 ICD with immediate mode support for all OGL primitive types
DirectX 9.0c

QuickSpecs

HP xw6200 Workstation

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 22 — June 6, 2005
