Cooling Cooling Cooling Cooling
Cooling Solutions
Supported
Yes
Power Supply Fan (Variable
Speed) 92 x 25 mm
Processor Fan-Heatsink
(Variable Speed) 70 x 15 mm
Chassis Fan (front) One 92 x 25 mm (optional)
Chassis Fan (rear) Two 92 x 25 mm (standard)
Internal Speaker Standard
Power Supply Power Supply Power Supply Power Supply
Full Ranging Input Yes
Active Power Factor
Correction (APFC) (Input
Current is nearly 1/2 a
non-APFC PS) Yes
Passive Power Factor
Correction (PFC) No
Operating Voltage Range 90 - 264 VAC/118 VAC
Rated Voltage Range 100 – 240 VAC
Rated Line Frequency 50-60 Hz/400Hz
Operating Line Frequency
Range 47 – 66 Hz/393 – 407Hz
Rated Input Current 9A/9A
Maximum Rated Power 500 W
Heat Dissipation Typical 1228.9 btu/hr
Maximum 1706 btu/hr
PS Size (wide x high x deep) 150 mm x 98 mm x 168 mm
Energy Star Compliant Yes
FEMP Standby Power
Compliant (<2W in S5 -
Power Off) No
Surge Tolerant Full
Ranging Power Supply Withstands power surges up to 2000V
Typical configuration
power consumption 2 processors (2x3.6GHz Xeon), 1 GB memory (2x512 MB)
Two hard drives (2xSATA 40 GB), DVD-ROM drive
PCI-Express Graphics Card (FX 1300)
Floppy, Monitor
Input Power consumption Input Power consumption Input Power consumption Input Power consumption @ 120Vac/60Hz @ 120Vac/60Hz @ 120Vac/60Hz @ 120Vac/60Hz
Typical operating mode
(system busy)
360 W = 1228.9 btu/hr
Windows XP Idle 201 W = 685.9 btu/hr
Hibernate mode (S4) 6.4 W = 21.84 btu/hr
Power Off (S5) 6.4 W = 21.84 btu/hr
ROM Features ROM Features ROM Features ROM Features Description Description Description Description
Instantly Available PC Allows for very low power consumption with quick resume time
QuickSpecs
HP xw6200 Workstation HP xw6200 Workstation HP xw6200 Workstation HP xw6200 Workstation
Technical Specifications
DA - 11975 Worldwide — Version 22 — June 6, 2005 Page 26
