System Board System Board System Board System Board
Architecture Xeon 64-bit/PCI-E
Chipset Intel E7525/ICH5R Chipset
Super I/O Controller SMSC LPC47B397
System Board Form Factor ATX (slightly larger than standard ATX)
Processor Socket Dual 604 Pin ZIF
DIMM Connectors (DDR2,
1.8V) 4
AGP Connector (1.5V) None
Integrated Graphics None
PCI Connectors (5.0V) 4 full length 33 MHz 32-bit
PCI Express Connectors 1 x16
1 x8 (with x4 electricals)
PCI card guide Optional, tool-free support for all full-length cards with PCI extender
Flash ROM Yes
AC97 integrated audio Yes
CD ROM IN (Audio) Yes
AUX IN (Audio) Yes
Clear CMOS Button Yes
CPU Fan Header Yes
Chassis Fan Header Yes
Chassis Speaker Header Yes
CMOS Battery Holder –
Lithium Yes
Hood Lock Header Yes
Hood Sensor Header Yes
Multibay Header Yes
Hard drive acoustic
dampening rails Standard in 2 internal 3.5" bays, tool-free
Integrated SATA RAID RAID 0 and RAID 1
Supports one RAID array on 2 ports
Creation of 2 drive HDD array
RAID 0 Configuration - Striped Array
RAID 1 Configuration - Mirrored Array
Integrated Broadcom Yes
NetXtreme Gigabit
Ethernet for HP Yes
Wake-On-Lan® Yes
ASF 1.0 (Alert Standard
Format) Yes
Power Supply Header Yes
Power Switch, Power LED
& Hard Drive LED Header Yes
Password Clear Header Yes
Riser Connector None
QuickSpecs
HP xw6200 Workstation HP xw6200 Workstation HP xw6200 Workstation HP xw6200 Workstation
Additional Technical Specifications
DA - 11975 Worldwide — Version 22 — June 6, 2005 Page 24
