Standard features - specs, Quickspecs, Hp xw6200 workstation – HP XW6200 User Manual
Page 6: Hp xw6200 workstation standard features - specs
Operating System (choice) Microsoft Windows XP Professional
Windows XP Professional x64 Edition (
)
OR Red Hat Enterprise Linux Workstation 3 Update 2 (64-bit only)
OR HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions on HP xw8200,
xw6200 and xw4200)
Form factor
Minitower
Color
Carbonite/Alloy metallic
System Board Form Factor Non-standard ATX
Processor
Single or dual 64-bit Intel Xeon processors (Nocona) with Hyper-Threading Technology
CPU Bus Speed Supported 800 MHz FSB
Standard L2 Cache
1 MB L2 cache
Chipset
Intel E7525
Memory Expansion Slots
4 DIMM's
Memory Type Supported
DDR-2 (ECC registered)
Memory Speed Supported DDR-2 Synch DRAM PC2-3200 (400 MHz) Registered ECC
Maximum Memory
8 GB (4 DIMMs slots, 2 GB DIMMs required to meet maximum configurations)
Network controller
Integrated Broadcom 5751 10/100/1000 for HP
Audio
Integrated AC'97 digital audio with S/PDif 6-channel pass-through, stereo microphone, and Yamaha XG
Lite Softsynth support
PCI slots
4 PCI slots (full-height)
1 PCI Express (x8 mechanically, x4 electrically)
1 PCI Express x16 graphics
AGP slot
none
Bays
Total Bays = 5
Internal Bays
Two 3.5 inch bays with acoustic dampening rail assemblies
External Bays
Two 5.25 inch full length 2003 mm maximum device depth (top bay is limited to 198 mm depth
when optional smart cover solenoid lock is installed). Bottom bay can be converted to an internal
3.5 inch 3rd Hard Drive bay using optional bracket
One 3.5 inch bay for optional floppy drive
Parallel Port
1
Serial Port
1
Front I/O
2 USB 2.0, Headphone, Microphone, optional IEEE 1394
NOTE:
NOTE:
NOTE:
NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux
) for details, and to the
IEEE 1394 Card.
Rear I/O
6 USB 2.0, 1 standard serial port, 1 parallel port, PS/2 keyboard and mouse, 1 RJ-45 to integrated
Gigabit LAN, Audio In, Audio Out, Mic In
USB Keyboard
Optional
USB Mouse
Optional
PS/2 Keyboard
1
PS/2 Mouse
1
Chassis Dimensions
(H x W x D)
17.3 x 6.5 X 17.3 in (44.1 x 16.5 x 44.0 cm)
System weight
Standard config – 35 lb
Shipping weight
Varies by region
Temperature
Operating
40° to 95° F (5° to 35° C)
Non-operating
-40° to 140° F (-40° to 60° C)
QuickSpecs
HP xw6200 Workstation
HP xw6200 Workstation
HP xw6200 Workstation
HP xw6200 Workstation
Standard Features - Specs
DA - 11975 Worldwide — Version 22 — June 6, 2005
Page 6
