E7525 chipset E7525 chipset E7525 chipset E7525 chipset
DDR-2 SDRAM ECC REGISTERED MEMORY
DDR-2 SDRAM ECC REGISTERED MEMORY DDR-2 SDRAM ECC REGISTERED MEMORY DDR-2 SDRAM ECC REGISTERED MEMORY
If only using one DIMM, install it in socket 1. For more than one DIMM, install memory in pairs (a pair would be considered to be
the DIMMs in sockets 1 & 2, 3 & 4) and do not mix speeds. It is always best to load the memory in pairs rather than a single DIMM
(two 512 MB DIMMs will have better performance than a single 1 GB DIMM). Each pair of DIMMs must be the same size and same
DRAM technology. The Intel E7525 chipset supports ECC Registered 400 MHz (PC2-3200) DDR-2 memory only.
MAXIMUM MEMORY
MAXIMUM MEMORY MAXIMUM MEMORY MAXIMUM MEMORY
Supports up to 8 GB of DDR SDRAM
POSSIBLE MEMORY CONFIGURATIONS
POSSIBLE MEMORY CONFIGURATIONS POSSIBLE MEMORY CONFIGURATIONS POSSIBLE MEMORY CONFIGURATIONS
Not all memory configurations possible are represented below.
DIMM Size DIMM Size DIMM Size DIMM Size Slot Slot Slot Slot
1 1 1 1 2 2 2 2 3 3 3 3 4 4 4 4
256 MB 256 MB
512 MB 512 MB
512 MB 256 MB 256 MB
1 GB 1 GB
1 GB 256 MB 256 MB 256 MB 256 MB
2 GB 1 GB 1 GB
2 GB 512 MB 512 MB 512 MB 512 MB
4 GB 1 GB 1 GB 1 GB 1 GB
8 GB 2 GB 2 GB 2 GB 2 GB
QuickSpecs
HP xw6200 Workstation HP xw6200 Workstation HP xw6200 Workstation HP xw6200 Workstation
Memory
DA - 11975 Worldwide — Version 22 — June 6, 2005 Page 22
