B
KLN 94
Rev. 4, Jan/2003 10599I04.CDL Page 2-3
NOTE
A right angle antenna connector is available from Honeywell
(P/N 030-00134-0001) or from TED.
2.3.5 ANTENNA MECHANICAL INSTALLATION
2.3.5.1 General
To maintain good performance from the antenna system, do not wax or paint the antenna.
2.3.5.2 Installation Procedure
A. Using the correct template for the antenna chosen, mark the mounting holes on the aircraft
fuselage.
B. Drill and/or punch the required holes.
CABLE
LENGTH
CABLE
PART NUMBER
BMA
CONNECTOR
TNC
CONNECTOR
MAXIMUM
ALLOWABLE
LOSS (dB)
0 to 40 ft P/N: 024-00002-0000
VPN: RG142B/U P/N: 030-00101-0002
VPN: TED Mfg. 9-30-10 P/N: 030-00134-0001
VPN: TED Mfg. 5-30-102 8.0
P/N: 024-00051-0060
VPN: RG400/U P/N: 030-00101-0002
VPN: TED Mfg. 9-30-10 P/N: 030-00134-0001
VPN: TED Mfg. 5-30-102 8.0
0 to 80 ft P/N: 024-00072-0000
VPN: ECS 311601 P/N: 030-00452-0000
VPN: TED Mfg. 9-30-26 P/N: 030-00108-0002
VPN: TED Mfg. 5-10-307 8.0
0 to 100 ft P/N: 024-00071-0000
VPN: ECS 311201 P/N: 030-00452-0001
VPN: TED Mfg. 9-30-25 P/N: 030-00108-0003
VPN: TED Mfg. 5-10-306 8.0
100 to 165 ft Contact TED, ECS or PIC for complete cable/connector assembly.
TED Manufacturing Corp. Electronic Cable Specialists PIC Wire and Cable
11415 Johnson Drive 5300 West Franklin Drive N53 W 24747 S. Corporate Circle
Shawnee, Kansas 66203 Franklin, Wisconsin 53132 P.O. Box 330
Tel: (913) 631-6211 Tel: (800) ECS-WIRE Sussex, Wisconsin 53089
or (414) 421-5300 Tel: (800) 742-3191
or (262) 246-0500
