B
KLN 94
Rev. 4, Jan/2003 10599I04.CDL Page A-12
B s ddd mmhh 10 present longitude; dash if position flag is set
s=sign: E for East, W for West
ddd=degrees
mm=minutes
hh=hundreths of minutes
C ddd 3 magnetic track, degrees; dash if GS is set
D ddd 3 groundspeed, knots; dash if position flag is set
E ddddd 5 10 x distance to active waypoint, nm; dash if
Nav Flag is set
G sdddd 5 crosstrack error; dash if Nav Flag is set
s=sign: R for aircraft position right of course, L
for aircraft position left of course.
dddd=1000 x crosstrack error, nm
I
(INDIA)
dddd 4 10 x magnetic desired track, degrees (use
selected course in OBS mode); dash if Nav Flag
is set.
K ddddd 5 active waypoint identifier
L dddd 4 10 x magnetic bearing to active waypoint,
degrees (use radial from active waypoint 180 in
OBS mode); dash if Position Flag is set.
Q sddd 4 magnetic variation; dash if Position Flag is set
s=sign: E for East, W for West
add=10 magnetic variation, degrees
T ---A----- warnings; 4th character is “A” if estimated
position error exceeds 3.8nm, otherwise “-”
l
(lima)
dddddd 6 10 x distance to destination, nm; dash if Nav
Flag is set
u free fromat for development testing only
w ddsiiiiilllLLLLmm 17 flight plan waypoint data; this item is sent for
each waypoint in the active flight plan
dd=waypoint number (01-25)
s=sequence number bits: 76543210
xlannnnn
x=unused, l=1 is last waypoint, a=1 if active wpt
nnnnn=sequential number, unassigned binary
iiiii=identifier
STANDARD RS232
Item
Designator
Data
Format
Data Field
Width
Description
