B
KLN 94
Rev. 4, Jan/2003 10599I04.CDL Page A-13
a Snnnnn 17 baro-corrected external altitude input
S=sign: + or -
nnnnn=altitude, feet (to nearest foot); dash if not
valid
j hh:mm:ss 8 UTC time of data
t abcdefghij 10 GPS discretes
a=W for waypoint alert; T for turn; else dashed
b=N for new message; P for persistent
message; else dashed
c=E for enroute; T for terminal; R for approach
arm; or A for approach active
d=L for leg; D for Direct-to; O for OBS; T for
OBS Æ LEG transition
e=T for TO; F for FROM; else dashed
fghij= reserved for future use; currently dashed
ENHANCED RS232
Item
Designator
Data
Format
Data Field
Width
Description
A s dd mmhh 9 present latitude; dash if position flag is set.
s=sign: N for north, S for south
dd=degrees
mm=minutes
hh=hundredths of minutes
B s ddd mmhh 10 present longitude; dash if position flag is set.
s=sign: E for east, W for west
ddd=degrees
mm=minutes
hh=hundredths of minutes
C ddd 3 magnetic track, degrees; dash if GS<2 kts or
position flag is set.
D ddd 3 groundspeed, knots; dash if position flag is set.
E
ddddd 5 10 ¥ distance to active waypoint, nm; dash if nav
flag is set.
STANDARD RS232
Item
Designator
Data
Format
Data Field
Width
Description
