HP XW6400X - Manual (Page 74)

Panel only (without stand) (H
x W x D) 12.96 x 15.9 x 2.4 inches
(32.91 x 40.39 x 6.1 cm)
Weight Unpacked with stand 15.6 lbs (7.06 kg)
Unpacked without stand 9.26 lbs (4.19 kg)
Packaged 20.5 lbs (9.27 kg)
Bezel Width 12.5 mm left and right, 12.75 mm top and bottom
Tilt Range -4 degrees to +30 degrees
Swivel Range ± 45 degrees horizontal swivel
Height Adjustable Yes (4 in/100mm adjustment range)
Pivot Rotation Yes, 90 degrees
Base Ships attached and is removable
Environmental Temperature –
Operating 41° to 95° F (5° to 35° C)
Temperature – Non-
operating -4° to 140° F (-20° to 60° C)
Humidity – Operating 20% to 80%
Humidity – Non-
operating 5% to 95%
Altitude – Operating 0 to 12,000 ft (0 to 3,658 m)
Altitude – Non-
operating 0 to 40,000 feet; 0 to 12,192 m
Environmental Data Eco-Label
Certifications and
Declarations This product has received or is in the process of being
certified to the following approvals and may be labeled
with one or more of these marks:
US Energy Star
CECP
Energy
Consumption
(in accordance with
US Energy Star test
method)
AC Input Voltage
at 100 VAC +/- 5
VAC, 50 Hz +/- 3
Hz
AC Input Voltage
at 115 VAC +/- 5
VAC, 60 Hz +/- 3 Hz
AC Input Voltage
at 230 VAC +/- 5
VAC, 50 Hz +/- 3
Hz
Normal Operation 35.7 watts 35.6 watts 35.1 watts
Sleep 1.08 watts 1.14watts 1.23 watts
Off 0.93 watts 0.94 watts 0.92 watts
Heat Dissipation* 100 VAC, 50 Hz 115 VAC, 60 Hz 230 VAC, 50 Hz
Normal Operation 121.7 BTU/hr 121.4 BTU/hr 119.7 BTU/hr
Sleep 3.68 BTU/hr 3.89 BTU/hr 4.19 BTU/hr
Off 3.17 BTU/hr 3.21 BTU/hr 3.14 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
Longevity and
Upgrading Upgradeability features contained in the product include:
One upstream and four downstream USB ports
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Monitors
DA - 12505 Canada — Version 27 — January 7, 2008 Page 74
