NOTE: HW RAID functionality not supported by Linux. Use SW RAID functionality provided in the Red Hat
Operating system instead.
SATA Connectors
4 ports/connectors
IEEE 1394a or 1394b
No integrated 1394a or 1394b – optional PCI card required.
Cable from Front IO can be plugged into PCI Card.
Not supported in Linux
USB 2.0 Connectors
8 (5 rear, 2 on header for front, 1 internal)
Power Supply Headers
Yes
Power Switch, Power LED
& Hard Drive LED Header
Yes
Password Clear Header
Yes
Cooling Solutions
Power Supply Fan
92x25 mm variable speed
Processor Heatsink Fan(s)
80x15 mm
Rear Chassis Fan(s)
Two 92x32 mm
Power Supply
Power Supply
575 Watt wide-ranging, active Power Factor Correction
Operating Voltage Range
90 – 269 VAC
Rated Voltage Range
100 – 240 VAC
118 VAC
Rated Line Frequency
50/60Hz
400Hz
Operating Line Frequency
Range
47–66Hz
393–407Hz
Rated Input Current
10 A @ 100-120VAC
6 A @ 200-240 VAC
9.7 @ 118 VAC
Heat Dissipation
(configuration and software
dependent)
Typical 980 btu/hr (247 kg-cal/hr)
Maximum 3413 btu/hr (860 kg-cal/hr)
Power Supply Fan
92x25 mm variable speed
Blue Angel Compliant
(<5w in S5 – power off)
N/A
FEMP Standby Power
compliant @ 115V
(<2W in S5 – power off)
YES
Power Consumption in ES
mMode – Suspend to RAM
(S3) (instantly available PC)
< 7 W
QuickSpecs
HP xw6400 Workstation
Technical Specifications
DA - 12505 Canada — Version 27 — January 7, 2008
