HP XW6400X - Manual (Page 28)

80 PLUS_Power Supply
Power Supply
575 Watt wide-ranging, active Power Factor Correction
Operating Voltage Range 90 – 269 VAC
Rated Voltage Range 100 – 240 VAC 118 VAC
Rated Line Frequency 50/60Hz 400Hz
Operating Line Frequency
Range 47–66Hz 393–407Hz
Rated Input Current 7A @ 100-120VAC
3 A @ 200-240 VAC
6.7 @ 118 VAC
Heat Dissipation
(configuration and software
dependent) Typical 699 btu/hr (176 kg-cal/hr)
Maximum 2804 btu/hr (706 kg-cal/hr)
Power Supply Fan 92x25 mm variable speed
Blue Angel Compliant
(<5w in S5 – power off) N/A
FEMP Standby Power
compliant @ 115V
(<2W in S5 – power off) YES
Power Consumption in ES
mMode – Suspend to RAM
(S3) (instantly available PC) < 7 W
ROM Features Description
ROM Based F10 Setup and
Diagnostics Review and customize BIOS settings
Remote System
Installation via F12 (PXE)
(remote boot from server) Allows a new or existing system to boot over the network and download software, including the operating
system
System/Emergency ROM
Flash Recovery with Video Recovers corrupted system BIOS
ROM Revision Levels Identifies system ROM revision levels and reports in ROM-based F10 setup
Version is stored in an industry standard memory location (SMBIOS) so that management SW
applications can use and report this information
System Board Revision
Level Allows management SW to read the revision level of the system board
Revision level is digitally encoded into the hardware and cannot be modified
Auto Setup when new
hardware installed System automatically detects addition of new hardware
Serial, Parallel, USB,
Audio, Network,
Enable/Disable Port
Control Enable or disables serial, parallel, USB, audio, and network ports
Removable Media Write/
Boot Control Prevents ability to boot from removable media on supported devices (and can disable writes to media)
Power-On Password Prevents an unauthorized person from booting up the computer
Setup Password Prevents an unauthorized person from changing the system configuration
QuickSpecs
HP xw6400 Workstation
Technical Specifications
DA - 12505 Canada — Version 27 — January 7, 2008 Page 28
