HP XW6400X - Manual (Page 54)

Available PCI slot
Regulatory Agency
Approval FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD,
Taiwan BSMI CNS13438, Korea MIC
PS/2 OR USB Standard
Keyboard Physical
characteristics Keys 104, 105, 106, 107, 109 layout (depending upon
country)
Dimensions (L x W x H) 18.0 x 6.4 x 0.98 inches; 45.8 x 16.3 x 2.5 cm
Weight 2 lb (0.9 kg) minimum
Electrical Operating voltage + 5VDC ± 5%
Power consumption 50-mA maximum (with three LEDs ON)
ESD CE level 4, 15-kV air discharge
EMI - RFI Conforms to FCC rules for a Class B computing
device
MicrosoftPC 99 - 2001 Functionally compliant
Mechanical Languages 38 available
Keycaps Low-profile design
Switch actuation 55-g nominal peak force with tactile feedback
Switch life 20 million keystrokes (using Hasco modified
tester)
Switch type Contamination-resistant switch membrane
Key-leveling mechanisms For all double-wide and greater-length keys
Cable length 6 ft (1.8 m)
Microsoft PC 99 - 2001 Mechanically compliant
Acoustics 43-dBA maximum sound pressure level
Environmental Operating temperature 50° to 122° F (10° to 50° C)
Non-operating
temperature -22° to 140° F (-30° to 60° C)
Operating humidity 10% to 90% (non-condensing at ambient)
Non-operating humidity 20% to 80% (non-condensing at ambient)
Operating shock 40 g, six surfaces
Non-operating shock 80 g, six surfaces
Operating vibration 2-g peak acceleration
Non-operating vibration 4-g peak acceleration
Drop (out of box) 26 inches; 66 cm on carpet, six-drop sequence
Drop (in box) 42 inches; 107 cm on concrete, 16-drop sequence
Operating system support Microsoft Windows Vista Business 32 or 64, Microsoft Windows XP
Professional, Microsoft Windows XP Professional x64 Edition, Red Hat
Enterprise Linux Workstation 3 and 4
Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
Ergonomic compliance ANSI HFS 100, ISO 9241-4, and TUVGS
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Input/Output Devices
DA - 12505 Canada — Version 27 — January 7, 2008 Page 54
