HP XW6400X - Manual (Page 73)

Preset VGA Mode 640 x 480 @ 60 Hz, 72 Hz
Preset SUN Mode 1152 x 900 @ 76 Hz
Fail Safe Mode Yes (limits out of range signal messages)
Maximum Pixel Clock
Speed 140 MHz
User Programmable
Modes Yes, 15
Anti-Glare Yes
Anti-Static Yes
AssetControl Yes (accessible on HP Compaq Business Desktops
featuring Intelligent Manageability)
Default Colour
Temperature Yes (6500k, 9300k, SRGB, Custom User)
On Screen Display (OSD)
Controls Buttons or Switches Power on/off; 3-button OSD; second level OSD
buttons include dual-input switch, dedicated auto
adjust switch
Languages English, Spanish, French, German, Netherlands, Italian,
Japanese, Simplified Chinese
User Controls Size and Positioning
Contrast
Brightness
Clock, Clock Phase
Selectable Colour Temperature
Serial Number
Mode Displayed
Sleep Timer
Input Selection
Factory Reset
Power Power Supply Auto-ranging, 90 to 265 VAC; internal power supply
Input Power 100 ~ 240 VAC
Nominal Current 1.5 A maximum
Frequency 50 ~ 60 Hz
Typical Power
Consumption < 35 watts
Maximum < 55 watts
Power Saving < 2 watts
Off Mode 0 watts (when master power switch is in the off position)
Power Cable Length 74.8 in (1.9 m); non-captive
Mechanical Dimensions
(H x W x D) Unpacked with stand 14.85 min to 18.79 max x
15.9 x 8.78 inches (37.72
min to 47.72 max x 40.39 x
22.29 cm)
Base Area
(Footprint D x W) 8.78 x 11.88 inches (22.29
x 30.18 cm)
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Monitors
DA - 12505 Canada — Version 27 — January 7, 2008 Page 73
