Quickspecs – HP XW6400X User Manual
Page 59
Operating Environmental
(all conditions non-
condensing)
Temperature (operating)
41° to 122° F (5° to 50° C)
Relative Humidity
(operating)
10% to 85%
Maximum Wet Bulb
Temperature (operating)
86° F (30° C)
Certifications, Approvals MMC II support, multi-read certification, Microsoft WHQL certification, ACA
AS/NZS 3548 class B, CNS 13438, C.I.S.P.R. Pub 22, TUV or VDE EN60950, EN
55022, EN55024, EMKO EN60950, EN 60825-1, UL 60950, CSA C22.2 60950-
2000, CFR 21 part 1040 class 1, CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA,
ANSI C63.4-1992
Operating Systems
Supported
Microsoft Windows 2000, Windows XP Professional
Kit Contents
16X/48X DVD-ROM Drive, InterVideo WinDVD MPEG Movie Playback software,
audio cable, and installation guide.
HP 48X Max SATA CD-
RW/DVD-ROM Combo
Drive
Form Factor
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc capacity
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM)
Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
Dimensions (W x H x D)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
Weight (max)
2.6 lb (1.2 kg)
Write speed
CD-R
Up to 48X
CD-RW
Up to 32X
Read speeds
DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 8X
DVD-ROM
Up to 16X
CD-ROM, CD-R
Up to 48X
CD-RW
Up to 32X
Buffer Size
1.5MB (Min)
Access times
(typical reads, including
setting)
Random
DVD: < 140 ms (typical), CD: < 125 ms (typical)
Full Stroke
DVD: < 250 ms (seek), CD: < 210 ms (seek)
Power
Source
SATA DC power receptacle
DC Power Requirement
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
DC Current
5 VDC - <1000 mA typical, < 1600 mA maximum
12 VDC - < 600 mA typical, < 1400 mA maximum
Total Drive Power
(standby mode)
< 2.5 Watt
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Optical Devices
DA - 12505 Canada — Version 27 — January 7, 2008
Page 59
