6-27
Configuring the Switch
Port Settings
Config
urin
g the Sw
itch
Configuring Port Parameters from the Switch Console
To Access Port Configuration:
1. From the Main Menu, select:
3. Switch Configuration...
2. Port Settings
Figure 6-11. Example of the Port Settings Screen
2. Press [E] (for Edit). The cursor moves to the Enabled field for the first port.
3. See table 6-2 on page 6-24 for the available values for each parameter and
definitions of each value. Or, refer to the online help provided with this
screen.
4. When you have finished making changes to the above parameters, press
[Enter], then press [S] (for Save) and return to the Switch Configuration
menu.
Read-Only Fields
