6-29
Configuring the Switch
Network Monitoring Port Features
Config
urin
g the Sw
itch
Configuring Port Monitoring from the Switch Console
To Access Port Monitoring:
1.
From the Main Menu, select:
3. Switch Configuration...
3. Network Monitoring Port
Figure 6-13. Network Monitoring Port Configuration Screen
2.
In the Actions menu, press
[E] (for Edit).
3.
If monitoring is currently disabled (the default) then enable it by pressing
the Space bar (or
[Y]) to select Yes).
4.
Press
[v] to display a screen similar to figure 6-13 and move the cursor to
the
Monitoring Port and Monitored Port parameters and type in the port
number or press the
[Space] bar to scroll through the available ports and
display the port you want to use for each of these functions.
5.
When you are finished, press
[Enter], then press [S] (for Save) and return to
the Switch Configuration menu.
Enable monitoring
by setting this
parameter to “Yes”.
