6-16
Configuring the Switch
SNMP Communities
Config
uri
ng the Sw
itch
To View, Edit, or Add SNMP Communities:
1.
From the Main Menu, select:
2. Switch Management Access Configuration (IP, SNMP, Console)...
2. SNMP Community Names/Authorized Managers
Figure 6-4. The SNMP Communities Screen (Default Values)
2.
From the Configuration screen, select SNMP Communities to display a
screen similar to the one above.
3.
Press
[A] (for Add) to display the following screen:
Add and Edit options are used to modify
the SNMP options. See figure 6-5.
Note: This screen gives an overview of the SNMP communities that
are currently configured. All fields in this screen are read-only.
