Specifications
C-2 HP Uninterruptible Power System T2200 XR Models User Guide
Input Specifications
Table C-2: Input Specifications
UPS Model
Utility
Voltage
Frequency
(Hz)
Default
Settings
Nominal
Voltage (VAC)
Available
Settings
Utility Voltage
(VAC)
Power Cord Supplied
T2200 XR NA 50/60 120 110, 120, 127 1 Non-detachable
power cord with
NEMA 5-20 plug
T2200 XR JPN 50/60 100 100 2 Non-detachable
power cord with
NEMA L5-30 plug
T2200 XR H NA 50/60 208 208 3 IEC-320-C14 input
power receptacle
T2200h XR H INT’L 50/60 230 220, 230, 240 IEC-320-C14 input
power receptacle
Note: 1 120 on battery
2 110 on battery
3
220 on battery
Before connecting devices, verify that the UPS will not overload by checking that the rating
of the devices does not exceed the capacity of the UPS. Evenly distribute connected devices
throughout all load segments. Do not exceed the rating of individual receptacles. Connect
devices according to shutdown preference.
After checking that the UPS will not overload, connect the power cords from the devices to
the appropriate output receptacles of the UPS.
WARNING: To prevent risk of personal injury from electric shock, the
UPS T2200 XR H NA and T2200 XR H INT’L models are not suitable for installation
where the total earth (ground) conductor leakage current for all connected devices
exceeds 3.5 mA.
