64 Hayes ADSL Ethernet User’s Guide
Connected = Network connection
established
Connected default = Network
connection is the default route.
Protocol Internet connection type
Auth (Authentication) Auto (CHAP or PAP),
CHAP, PAP, None. See page 32.
IP Address ADSL Ethernet’s WAN IP address.
Primary DNS IP address of Primary DNS Server
Secondary DNS IP address of Secondary DNS Server
4.2 System Status
The System Status page of your Configuration Manager displays
the following information:
Software Version Version and release numbers
State “Showtime” indicates that there is a DSL
connection.
