40 Hayes ADSL Ethernet User’s Guide
Passthrough
Host MAC
–for example, 00:01:03:24:F0:B6. For
instructions on locating a MAC address, see
User ID
The name you entered and saved on the
Basic Setup page is displayed.
Password
The password you entered and saved on the
Basic Setup page is displayed.
Inactivity
Disconnect
Timer
The period of inactivity on the line after
which the connection will be terminated –
never (the default), 1 minute, 5 minutes, 20
minutes, or 1 hour.
Keep Alive
Timer
The amount of time between automatic “Are
you still there?” exchanges between modem
and service provider – never (never check), 1
second, 30 seconds (default), 10 minutes,
or 1 hour.
Traffic Profile
The index number 0-7 of a previously
configured profile defining the Quality of
WAN IP Filter
The index number 0-7 of a previously-
configured WAN IP filter. See page 42.
Default Route
Selected is the default. The Default Route
controls which connection will be used for
default IP gateway routing. Only one
connection can have this option selected.
RIP Mode
(Routing Information Protocol Mode). See
Virtual Circuit
An index number 0-7. See the definition on
When you finish the configuration, follow these steps:
a
a
a
a
Click Update. The modem begins a new search of its
connection with your DSL provider to find the provider’s
Internet settings.
