34 Hayes ADSL Ethernet User’s Guide
3.1.2 1483 Bridged with DHCP
If you selected this protocol on the Basic Setup page of your
Configuration Manager, the following fields appear:
Make these entries:
Enable Lets you enable or disable the connection.
VPI Supplied by your service provider.
VCI Supplied by your service provider.
Encapsulation LLC or VC. Supplied by your service
provider. See page 31.
MAC Address The modem’s MAC address (display only).
Traffic Profile The index number 0-7 of a previously
configured profile defining the Quality of
Service. See page 54.
WAN IP Filter The index number 0-7 of a previously-
configured WAN IP Filter. See page 42.
Default Route Selected is the default for Virtual Circuit 0.
See page 33.
RIP Mode (Routing Information Protocol Mode). See
page 33.
