Havis-Shields Kwik-Kit KK-100-06 User Manual
Page 7
KK-XXX-06_INST_8-07
7
The following photos are the main subassemblies as they are shipped from the factory.
Remove drawing on final page and reference the item #’s as you install this kit.
Driver Side Bench/Wall/
Front bulkhead wing section
Driver-side ceiling
Item #7
Center Divider
Item #5
Passenger Side Rear Bench/Wall/
3
rd
Compartment Bulkhead
Wing section
Item #2
Front Bulkhead minus driver-side
Wing section
Item #3
3
rd
compartment bulkhead
Item #9
3
rd
Compartment bench w/ optional
storage door
Item #10
Passenger-side rear ceiling
Item #8
Item #1
(2) - Diamond plate floor
Item #4 & 13
