An awe or scribe will help
align the holes
THE FOLLOWING STEPS ARE EXTREMLY CRITICAL FOR A SUCCESFULL
INSTALLATION! PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY.
Item #1
Rear driver-side
doorframe wing
Position of driver-side Rear
Doorframe when insta ling with
factory rear air There should be at
least ¼” of space between the
A/C blower motor and wing
l
8”inches
Lower Driver-Side rear
Measurement from driver-side
Rear Doorframe to vehicle
e shown above doorfram
8” inches
Lower Passenger-Side rear
Measurement from passenger-side
Rear Doorframe to vehicle
doorframe shown above
Cut door gasket with utility kni
of door acceptor fram
fe. Cut gasket to the length
e. Attach as shown above.
Position the entire unit according to the
measurements on the following page.
Note: Maneuver the kit into position.
Tighten screws holding Rear
Doorframe to Center Divider
Item #6
to
Item #7, #8, #12 to
#5
Continue around the entire kit bolting
all Ceiling pieces to Bulkheads and
Doorframes using ¼ x ¾” carriage
bolts, washers, and serrated nuts
#3, & #6
¼”
Pry bar
