Havis-Shields Kwik-Kit KK-100-06 User Manual
Page 10
KK-XXX-06_INST_8-07
10
Place Driver-side Bench/Wall
assembly into van so bench rests
on wheel well
Item #1
Remove steel support bracket for
Emergency Exit Hatch pin. Re-install
when attaching Front Bulkhead to
Bench/Wall assemblies
Item #3
Item #2
Place Passenger-side
Bench/Wall assembly into van so
bench rests on wheel well
Remove Emergency Exit Hatch
from Front Bulkhead to ease
installation
Item #3
View of Emergency Exit Hatch
support bracket assembled.
Item #3
Item #3
Item #3
Place Front Bulkhead into
vehicle
Attach Front Bulkhead to
Driver-side Bench/Wall
assembly
